Display

Model


DHI-LM22-C201P

LCD Technology


IPS

Backlight


ELED

Screen Size


21.5 inch

Aspect Ratio


16:9

Resolution


1920 (H) × 1080 (V)

Refresh Rate


100 Hz

Display Color


8 bit

Color Gamut


72% NTSC

Brightness


250 cd/m2 (typ.)

Contrast Ratio


1000: 1

Viewing Angle


178° (H) / 178° (V)

Display Mode


Horizontal

Response Time


OD 5 ms

Lifespan


30,000 hrs

Surface Treatment


Haze 25%, 3H

Device Ports

Input Port


1 × HDMI 1.4 (1920 × 1080@100 Hz), 1 × VGA (1920 × 1080@60 Hz)

Output Port


1 × Audio out

Power & Environmental Conditions

Power Supply


12 VDC, 2 A

Power Type


power adapter

Power Consumption


15 W (basic), 15 W (typ.), 24 W (max)

Standby Power Consumption


< 0.5 W

Operating Temperature


0 °C to +40 °C (+32 °F to +104 °F)

Operating Humidity


10%–85% (RH)

Storage Temperature


–10 °C to +50 °C (+14 °F to +122 °F)

Storage Humidity


5%–95% (RH)

General

Inclined Angle


-5° ± 2° / 15° ± 2°

Product Dimensions


492.8 mm × 368.5 mm × 222.7 mm (19.40" × 14.51" × 8.77") (W × H × D), with stand

Package Size


561 mm × 429 mm × 152 mm (22.09" × 16.89" × 5.98") (W × H × D)

Frame Width


U/L/R/D: 2 mm/2 mm/2 mm/15 mm

Net Weight


2.64 kg (5.82 lb)

Gross Weight


4.14 kg (9.13 lb)

Accessory


Power adapter, HDMI cable, user's manual, legal and regulatory information etc.
