INTEL 6-core Xeon E-2236 3.4GHZ/12MB/FCLGA1151/80W

Specifications:
Product Collection   Intel® Xeon® E Processor
Code Name  Products formerly Coffee Lake
Vertical Segment Server
Processor Number E-2236
Lithography  14 nm

Performance:
# of Cores  6
# of Threads  12
Processor Base Frequency  3.40 GHz
Max Turbo Frequency  4.80 GHz
Cache  12 MB
TDP  80 W

Memory Specifications:
Max Memory Size (dependent on memory type)  128 GB
Memory Type  DDR4-2666
Max # of Memory Channels  2
ECC Memory Supported ‡  Yes

Processor Graphics:
Processor Graphics ‡  N/A
Graphics Output  N/A
4K Support  No
Max Resolution (HDMI 1.4)‡  N/A
Max Resolution (DP)‡  N/A
Max Resolution (eDP - Integrated Flat Panel)‡  N/A
Max Resolution (VGA)‡  N/A
DirectX* Support  N/A
OpenGL* Support  N/A
Intel® Quick Sync Video  No
Intel® InTru™ 3D Technology  No
Intel® Clear Video HD Technology  No
Intel® Clear Video Technology  No
Device ID N/A

Expansion Options:
Scalability 1S Only
PCI Express Revision  3.0
PCI Express Configurations ‡  1x16,2x8,1x8+2x4
Max # of PCI Express Lanes  16

Package Specifications:
Sockets Supported  FCLGA1151
Max CPU Configuration 1
TCASE  73°C
TJUNCTION  100
Package Size 37.5 mm x 37.5 mm

Advanced Technologies:
Intel® Optane™ Memory Supported ‡  Yes
Intel® Turbo Boost Technology ‡  2.0
Intel® vPro™ Platform Eligibility ‡  Yes
Intel® Hyper-Threading Technology ‡  Yes
Intel® Virtualization Technology (VT-x) ‡  Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡  Yes
Intel® VT-x with Extended Page Tables (EPT) ‡  Yes
Intel® TSX-NI  Yes
Intel® 64 ‡  Yes
Instruction Set  64-bit
Instruction Set Extensions  Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States  Yes
Enhanced Intel SpeedStep® Technology  Yes
Thermal Monitoring Technologies  Yes

Security & Reliability:
Intel® AES New Instructions  Yes
Secure Key  Yes
Intel® Software Guard Extensions (Intel® SGX)  Yes with Intel® ME
Intel® Memory Protection Extensions (Intel® MPX)  Yes
Intel® OS Guard Yes
Intel® Trusted Execution Technology ‡  Yes
Execute Disable Bit ‡  Yes
Intel® Boot Guard  Yes
